RFE ABF3000 Automatic Patty Maker – High-Volume Commercial Patty Production
Updated:
The RFE ABF3000 Auto Patty Maker is a powerful, fixed-speed patty forming solution
engineered for high-output commercial production. Designed to streamline burger patty
manufacturing for butcheries, food processors and central kitchens, the ABF3000 delivers
up to 3000 patties per hour with consistent accuracy and hygienic operation.
Why Choose RFE Patty Forming Systems?
RFE equipment is known across Australia for reliability, hygiene and long service life. The ABF Series offers:
- Trusted performance in meat-processing environments
- Stainless-steel paddles for durability and hygiene
- Tool-free disassembly for easy daily cleaning
- Industrial-grade motors designed for long sessions of continuous use
Streamlined Commercial Patty Production
Built for efficiency, the ABF3000 uses a fixed-speed motor and foot-pedal control
to maintain consistent output. A 16L hopper supports uninterrupted production, while
the 390mm conveyor allows continuous flow into trays or downstream equipment.
Key Features & Specifications
- Production Output: Up to 3000 patties/hr (fixed speed)
- Motor: 750W industrial motor
- Power: 240V / 50Hz
- Max Patty Diameter: 130mm
- Min Patty Diameter: 50mm
- Max Patty Width: 32mm
- Hopper Capacity: 16 litres (larger sizes optional)
- Conveyor: 390mm standard conveyor
- Construction: Heavy-duty frame + stainless-steel paddle
- Cleaning: No dismantling tools required
- Dimensions (L×W×H): 700 × 580 × 760 mm
- Weight: 66kg
Compliance & Safety (AU)
- Commercial food-processing compliant
- Safe fixed-speed foot-pedal operation
- Hygienic stainless-steel components for food-contact areas
- Stable, heavy-duty frame for continuous production
Convenience & Workflow Benefits
- Uniform patty size: Reliable shape and thickness
- Rapid production: Ideal for medium to large batch operations
- Modular upgrades: Optional double drum + 900mm conveyor
- Easy cleaning: Tool-free disassembly speeds up sanitation
Ideal Applications
- Food manufacturers & central kitchens
- Butcher shops & patty processors
- Commercial burger production
- Frozen food and OEM suppliers
Watch the ABF Series in Action
Smart Energy & Sustainability
Energy Use
750W motor with efficient fixed-speed output.
Estimated daily consumption (2–3 hours): 1.5–2.3 kWh/day
Running Cost Estimate
2.3 kWh × $0.30/kWh = approx. $0.69/day
CO₂ Output (AU Grid)
2.3 kWh × 0.79kg = 1.81 kg CO₂/day
Sustainability Highlights
- Low energy consumption for volume output
- Durable stainless-steel paddle extends machine life
- Tool-free dismantling reduces chemical usage
Eco Badges: ⚡ Low Energy | ???? Easy Clean | ???? Long-Life Build
At a glance
- 3000 patties/hr output
- Fixed-speed industrial motor
- 16L hopper + 390mm conveyor
- Durable stainless-steel construction
Ready to upgrade your production line?
Call 1300 001 366 or
Contact our team.
Browse
Meat Processing Equipment
. Fast AU-wide delivery.
Specifications sourced from RFE ABF2000/3000 technical sheet.
